35W LED Downlight With SAA CE ROHS

FEATURES

  • Up to 70% energy saving compared to standard CFL
  • Long lifetime of 40,000 hours
  • Dimmable when using triac dimmer
  • 36°/60° wide beam angle
  • CCT: 2700K 3000K 4000K 5000K
  • No UV/IR light
  • Environment friendly, without Mercury or any other hazardous substances

CHARACTERISTIC

power factorled beam angle 60 degree ip54 waterproofeasy installation

APPLICATION AREAS

retail store lightingrestaurant lightingoffice lightingclassroom lightinginterior lighting ideas

CERTIFICATIONS

ce certificationRoHs certificationsaa certification

POLAR DIAGRAM COMPARISON

35w recessed downlight sizes

DIMENSION

led surface mount downlight polar chart3000k led downlight Dimensions Diagram

TECHNICAL SPECIFICATIONS

Power Voltage Power Factor Lumen (±5%) Beam angle CCT Lifespan CRI Dimmable Dimension
35W AC100-240V ≥0.9 3150 60° 2700K 40000h ≥80 No Ø90*100mm
35W AC100-240V ≥0.9 3320 60° 3000K 40000h ≥80 No Ø90*100mm
35W AC100-240V ≥0.9 3430 60° 4000K 40000h ≥80 No Ø90*100mm
35W AC100-240V ≥0.9 3360 60° 5000K 40000h ≥80 No Ø90*100mm
35W AC230V ≥0.9 3100 60° 2700K 40000h ≥80 Yes Ø90*100mm
35W AC230V ≥0.9 3290 60° 3000K 40000h ≥80 Yes Ø90*100mm
35W AC230V ≥0.9 3400 60° 4000K 40000h ≥80 Yes Ø90*100mm
35W AC230V ≥0.9 3320 60° 5000K 40000h ≥80 Yes Ø90*100mm
