The appearance of this spike light is derived from the aircraft engine, with a strong visual impact, high recognition, simplicity, and elegance, and the installation is also simple and quick. The lamp body is made of ADC12 aluminum, which has strong heat dissipation, corrosion resistance, and anti-aging ability. To meet a wider application use, this lamp has four types: AC220V and AC/DC12V with ground install and board install option, all these four types can have external waterproof connectors for quick wiring. It is a good lighting choice for gardens, exterior walls, fences, etc.
Application Areas: It applies to landscaping embellishment lighting for residences and communities and all kinds of parks.
Code | TL129-65-10W | TL129-65-15W | TL129-85-20W | TL129-85-25W | TL129-85-27W-D | TL129-85-28W |
---|---|---|---|---|---|---|
Dimension(mm) | Ø65*H96 | Ø85*H130 | ||||
Watt(W) | 10W | 15W | 20W | 25W | 27W | 28W |
Rated Input Voltage(V) | AC220-240V | |||||
Input Voltage(V) | AC198-264V | |||||
LED Module Input | DC33-38V | |||||
Light Source | COB | |||||
SDCM | <5 | |||||
CCT(K) | 1-CCT: 2700K/3000K/4000K/5000K || 3-CCT: 3000K+4000K+5000K | |||||
CCT Selection DIP Switch | YES | |||||
Non-DIM 1-CCT Luminous Flux (lm) ±5% CRI80 | 1150-1250 | 1550-1700 | 2200-2300 | 2650-2850 | - | 3100-3300 |
DIM 1-CCT Luminous Flux (lm) ±5% CRI80 | 1150-1250 | 1550-1700 | 2200-2300 | 2650-2850 | 3000-3100 | 3100-3300 |
Non-DIM 3-CCT Luminous Flux (lm) ±5% CRI90 | 900-950 | 1150-1300 | 2000-2150 | 2150-2250 | - | 2400-2700 |
DIM 3-CCT Luminous Flux (lm) ±5% CRI90 | 900-960 | 1220-1300 | 1700-1850 | 2150-2400 | 2300-2400 | 2400-2700 |
Black color decrease 10% lumen | ||||||
CRI | 1-CCT: 80; 3-CCT: 90 | |||||
Beam Angle (°) | 24°/ 36°/ 50° | |||||
UGR | <19 | <22 | ||||
LED Driver | Driver built-out | |||||
Dimming Option | Triac/ DALI | |||||
Electrical Class | Class II | |||||
Ingress Protection(IP Rating) | IP20 | |||||
Product Finishing | White RAL9016, Black RAL9005 | |||||
Optics Material | TL129-65 PC, TL129-85 AL1090 | |||||
Housing Material | Aluminium | |||||
Lifetime (hr) | 50,000h | |||||
Glow wire test (°C) | 750°C | |||||
Operating Temp.(°C) | -20°C~30°C | |||||
Storage Temp.(°C) | -20°C~65°C | |||||
Installation | Track |
